|Product #:||29787||Product Line:||DOT (DOT LED Blank-Out Sign)|
|Model:||DOT3030DRAG-B295/100-240VAC||Dimensions:||30" H x 30" W x 11.5" D|
|Weight:||93.483 lbs.||Faces:||Double Face|
|Illumination:||TCL LED||Integral Hood:||No Hood|
|DOT Integral Mount Tabs:||No Mounting Tabs||Input Voltage:||100-240 VAC|
|LED Viewing Angle:||Narrow Angle LEDs||Cabinet:||DOT Double Face 11.5"|
|Face Material:||1/4" Smoke Polycarbonate (5109)||UL/cUL Listed:||Wet Locations|
|Power Supplies:||Redundant||Mounting Channel:||None|
|Warranty:||5 Year Warranty|
Please contact us for mounting recommendations.
5 Year Warranty
Our warranty starts from the original date of shipment and runs through the life of the stated warranty period. Should any component become defective during the warranty period, the component or entire unit, at the discretion of Signal-Tech, will be replaced at no charge to the customer; this excludes labor cost to remove and/or reinstall the component or unit.
To learn more about our warranty, click here.
The X | X | Down Arrow | X | X | Down Arrow, NEMA-4X Cabinet (100-240VAC) sign is a direct-view LED design with three independent messages. It illuminates the first 'X', in Red LEDs, the second 'X' in Amber LEDs, the 'Down Arrow' in Green LEDs and blanks out when off. Outside cabinet dimensions are 30" x 30" x 9"D.
The sign is engineered with super-bright, narrow viewing angle LEDs for optimal viewing in a roadway application. Conformal coated circuit board protects electronic components from outside elements and the contrasting polycarbonate sign face enhances message readability. The sign features fail-safe, redundant power supplies and automatic photo-dimming which adjusts the message brightness to the ambient lighting conditions.
It is housed in a corrosion resistant, extruded aluminum cabinet with welded seams; NEMA-4X rated/IP66. Optional visor available. The cabinet features a continuous hinged door; tool-less, stainless-steel locking clamps; and a replaceable 1/4" thick impact resistant polycarbonate face. Standard cabinet finish is black powder coat; custom colors available. UL/cUL Listed. Suitable for wet locations.
