|Product #:||38325||Product Line:||DOT (DOT LED Blank-Out Sign)|
|Model:||DOT3630RW-D572/100-240VAC||Dimensions:||36" H x 30" W x 5" D|
|Weight:||59.379 lbs.||Faces:||Single Face|
|Illumination:||TCL LED||Integral Hood:||No Hood|
|DOT Integral Mount Tabs:||No Mounting Tabs||Input Voltage:||100-240 VAC|
|LED Viewing Angle:||Narrow Angle LEDs||Cabinet:||DOT Single Face 5.130"|
|Face Material:||1/4" Smoke Polycarbonate (5109)||UL/cUL Listed:||Wet Locations|
|Power Supplies:||Redundant||Mounting Channel:||None|
|Warranty:||5 Year Warranty|
5 Year Warranty
Our warranty starts from the original date of shipment and runs through the life of the stated warranty period. Should any component become defective during the warranty period, the component or entire unit, at the discretion of Signal-Tech, will be replaced at no charge to the customer; this excludes labor cost to remove and/or reinstall the component or unit.
To learn more about our warranty, click here.
The NO TURN ON RED w/ 6 in dia Indicator Dot, NEMA 4X Cabinet (100-240VAC) sign is a direct-view LED design that illuminates red/white when activated and blanks out when deactivated. Outside cabinet dimensions are 36.000" x 30.000" x 5.000".
The sign is engineered with super-bright, narrow viewing angle LEDs for optimal viewing in a roadway application. Conformal coated circuit board protects electronic components from outside elements and the contrasting polycarbonate sign face enhances message readability. The sign features fail-safe, redundant power supplies and automatic photo-dimming which adjusts the message brightness to the ambient lighting conditions.
It is housed in a corrosion resistant, extruded aluminum cabinet with welded seams; NEMA-4X rated/IP66. Optional hood available. The cabinet features 1/4" thick impact resistant polycarbonate face. Standard cabinet finish is black powder coat; custom colors available. UL/cUL listed. Suitable for wet locations.
